Flash Buttons With Rollover Effect
Good day everyone, today, we will be creating buttons flash buttons with a rollover effect.
Create Simple button
1. Select rectangle tool (use red for fill)
2. click and drag a rectangle shape on stage
3. right-click rectangle shape, and select Convert to Symbol
4. enter name for symbol, eg. shapeOfBtn
5. change Type to Movie Clip
6. click OK, to create new symbol
note: the shape which was on the stage will now be changed to an instance of the new symbol
7. right-click instance of the symbol, and select Convert to Symbol
8. enter name for symbol, eg. btnTest
9. change Type to Button
10. click OK, to create new symbol, which is of type button
Create rollover effect for button instance
1. double-click button instance, to access ‘master’ symbol (the addressbar will show Scene 1 btnTest, to show that you are inside Scene 1, and editing master symbol of btnTest)
2. click in frame called Over
3. press F6, to insert Keyframe
4. single-click the shapeOfBtn instance, for over frame
5. select Tint from Color dropdown box
6. click color box beside the Color dropdown box, and select green color
7. enter value of tint amount, eg. 100%
8. select Scene 1 of address bar, to return to main timeline (addressbar will change to only show Scene 1, when you have returned to main timeline)
9. press Ctrl + S, to save file
10. press Ctrl + Enter, to export test movie (as expected, when mouse is not over button, its red, but when mouse is over button, the button turns green)
